War thunder screen15

A KV tank




The Kliment Voroshilov (KV) tanks were a series of Soviet heavy tanks named after the Soviet defense commissar and politician Kliment Voroshilov and used by the Red Army during World War II. The KV series were known for their extremely heavy armour protection during the early part of the war, especially during the first year of the German invasion of the Soviet Union.

They were almost completely immune to the 3.7 cm KwK 36 and howitzer-like, short barreled 7.5 cm KwK 37 guns mounted respectively on the early Panzer III and Panzer IV tanks fielded by the invading German forces. Until better guns were developed by the Germans it was often the case that the only way to defeat a KV was with a point-blank shot to the rear.

Prior to Operation Barbarossa (the German invasion of the USSR), about 500 of the over 22,000 tanks then in Soviet service were of the KV-1 type. When the KV-1 appeared, it outclassed the French Char B1, the only other heavy tank in operational service in the world at that time. Yet, in the end, it turned out that there was little sense in producing the expensive KV tanks, as the T-34 medium tank performed better (or at least equally well) in all practical respects. Later in the war, the KV series became a base for the development of the IS (IS - Josif Stalin) series of tanks.

Development historyEdit

After disappointing results with the multi-turreted T-35 heavy tank, Soviet tank designers started drawing up replacements. The T-35 conformed to the 1920s notion of a 'breakthrough tank' with very heavy firepower and armour protection, but suffered from poor mobility. The Spanish Civil War demonstrated the need for much heavier armor on tanks, and was the main influence on Soviet tank design just prior to World War II.

The doctrine of Soviet deep battle called for the existence of relatively immobile, but heavily fortified, siege tanks that were supposed to keep pressure on enemy troops during the siege phase. Thus, the requirements for KV-1 were heavily skewed towards a potentially not-so agile, but heavy tank that was supposed to dominate the field.

Several competing designs were offered, and even more were drawn up prior to reaching prototype stage. All had heavy armour, torsion-bar suspension, wide tracks, and were of welded and cast construction. One of the main competing designs was the SMK, which in its final form had two turrets, mounting the same combination of 76.2 mm and 45 mm weapons. The designers of the SMK independently drew up a single-turreted variant and this received approval at the highest level. Two of these, named after the People's Defence Commissioner were ordered alongside a single SMK. The smaller hull and single turret enabled the designer to install heavy frontal and turret armour while keeping the weight within manageable limits. Abandoned KV-2, June 1941When the Soviets entered the Winter War, the SMK, KV and a third design, the T-100, were sent to be tested in combat conditions. The KV outperformed the SMK and T-100 designs. The KV's heavy armour proved highly resistant to Finnish anti-tank weapons, making it more difficult to stop. In 1939, the production of 50 KVs was ordered. During the War, the Soviets found it difficult to deal with the concrete bunkers used by the Finns and a request was made for a tank with a large howitzer. One of the rush projects to meet the request put the howitzer in a new turret on one of the KV tanks.

Initially known as Little Turret and Big turret, the 76-mm-armed tank was designated as the KV-1 Heavy Tank and the 152 mm howitzer one as KV-2 Heavy Artillery Tank.

The KV's strengths included armor that was impenetrable by any tank-mounted weapon then in service except at point-blank range, that it had good firepower, and that it had good traction on soft ground. It also had serious flaws: it was difficult to steer, the transmission (which was a twenty year old Caterpillar design) was unreliable (and was known to have to be shifted with a hammer), and the ergonomics were poor, with limited visibility and no turret basket. Furthermore, at 45 tons, it was simply too heavy. This severely impacted the maneuverability, not so much in terms of maximum speed, as through inability to cross many bridges medium tanks could cross. The KV outweighed most other tanks of the era, being about twice as heavy as the heaviest contemporary German tank. KVs were never equipped with a snorkelling system to ford shallow rivers, so they had to be left to travel to an adequate bridge. As applique armor and other improvements were added without increasing engine power, later models were less capable of keeping up to speed with medium tanks and had more trouble with difficult terrain. In addition, its firepower was no better than the T-34. It took field reports from senior commanders "and certified heroes", who could be honest without risk of punishment, to reveal "what a dog the KV-1 really was."

While initially the Soviets made a lot of poor defense decisions, worsened by recent "cleansings" of Soviet military command, the KV-1 was unlike anything the German army had expected to encounter, and some of the battles against numerically superior Axis forces became legendary. Even though the operations of the KV family of tanks were severely hampered by restrictions due to its weight, it was a fearsome and formidable weapon through most of the Second World War.

Further developmentEdit

By 1942, when the Germans were fielding large numbers of long-barrelled 50 mm and 75 mm guns, the KV's armor was no longer invincible. The KV-1's side, top, and turret armor could also be penetrated by the high-velocity MK 101 carried by German ground attack aircraft, such as the Henschel Hs 129, requiring the installation of additional field-expedient appliqué armour. The KV-1's 76.2 mm gun also came in for criticism. While adequate against all German tanks, it was the same gun as carried by smaller, faster, and cheaper T-34 medium tanks. In 1943, it was determined that this gun could not penetrate the frontal armour of the new Tiger, the first German heavy tank, fortuitously captured near Leningrad. The KV-1 was also much more difficult to manufacture and thus more expensive than the T-34. In short, its advantages no longer outweighed its drawbacks.

Nonetheless, because of its initial superior performance, the KV-1 was chosen as one of the few tanks to continue being built following the Soviet reorganization of tank production. Due to the new standardization, it shared the similar engine (the KV used a 600 hp V-2K modification of the T-34's V-2 diesel engine) and gun (the KV had a ZiS-5 main gun, while the T-34 had a similar F-34 main gun) as the T-34, was built in large quantities, and received frequent upgrades.

When production shifted to the Ural Mountains 'Tankograd' complex, the KV-2 was dropped. While impressive on paper, it had been designed as a slow-moving bunker-buster. It was less useful in highly mobile, fluid warfare that developed in World War II. The turret was so heavy it was difficult to traverse on uneven terrain. Finally, it was expensive to produce. Only about 300 KV-2s were made, all in 1940-41, making it one of the rarer Soviet tanks. KV-1 produced in 1942, displayed in Finnish Tank Museum in Parola.As the war continued, the KV-1 continued to get more armour to compensate for the increasing effectiveness of German weapons. This culminated in the KV-1 model 1942 (German designation KV-1C), which had very heavy armour, but lacked a corresponding improvement to the engine. Tankers complained that, although they were well-protected, their mobility was poor and they had no firepower advantage over the T-34 medium tank.

In response to criticisms, the lighter KV-1S was released, with thinner armour and a smaller, lower turret in order to reclaim some speed. Importantly, the KV-1S also had a commander's cupola with all-around vision blocks, a first for a Soviet heavy tank. However, the thinning-out of the armor called into question why the tank was being produced at all, when the T-34 could seemingly do everything the KV could do and much more cheaply. The Soviet heavy tank program was close to cancellation in mid-1943.

The appearance of the German Panther tank in the summer of 1943 convinced the Red Army to make a serious upgrade of its tank force for the first time since 1941. Soviet tanks needed bigger guns to take on the growing numbers of Panthers and the few Tigers.

A stopgap upgrade to the KV series was the short-lived KV-85 or Objekt 239. This was a KV-1S with a new turret designed for the IS-85, mounting the same 85 mm D-5T gun as the SU-85 and early versions of the T-34-85; demand for the gun slowed production of the KV-85 tremendously and only 148 were built before the KV design was replaced. The KV-85 was produced in the autumn and winter of 1943-44; they were sent to the front as of September 1943 and production of the KV-85 was stopped by the spring of 1944 once the IS-2 entered full scale production.


A new heavy tank design entered production late in 1943 based on the work done on the KV-13. Because Kliment Voroshilov had fallen out of political favour, the new heavy tank series was named the Josif Stalin tank, after Josif (Joseph) Stalin. The KV-13 program's IS-85 prototype was accepted for production as the IS-1 (or IS-85, Object 237) heavy tank. After testing with both 100 mm and 122 mm guns, the D-25T 122 mm gun was selected as the main armament of the new tank, primarily because of its ready availability and the effect of its large high-explosive shell when attacking German fortifications. The 122mm D-25T used a separate shell and powder charge, resulting in a lower rate of fire and reduced ammunition capacity. While the 122mm armour piercing shell had a lower muzzle velocity than similar late German 7.5 cm and 8.8 cm guns, proving-ground tests showed that the 122mm AP shell could defeat the frontal armour of the German Panther tank, and the HE shell would easily blow off the drive sprocket and tread of the heaviest German tank or self-propelled gun. The IS-122 replaced the IS-85, and began mass production as the IS-2. The 85 mm gun saw service in the lighter SU-85 and T-34-85. A destroyed Soviet KV-1 in Olonets, September 1941, during the Continuation War

The Soviets did not recognize different production models of KV-1 during the war; designations like model 1939 (M1939, Russian: Obr. 1939) were introduced later in military publications. These designations, however, are not strict and describe leading changes, while other changes might be adapted earlier or later in specific production batches. Designations like KV-1A were applied by the Germans during the war.
220px-Kv1 m1942 parola 1
